Who invented the Modbus protocol?

The communication protocol known today as Modbus stands as one of the most enduring and widespread methods for industrial data exchange, essentially serving as a foundational language for connecting disparate control devices across different manufacturers. While the underlying technology has been adapted and wrapped in modern networking layers, its genesis lies firmly in the late 1970s, conceived by a company deeply embedded in the world of programmable logic controllers (PLCs). The origins of this protocol trace directly back to Modicon, a name synonymous with early automation technology, which eventually became part of Schneider Electric.

# Modicon's Genesis

The creation of Modbus was driven by a very practical need within the automation sphere: the desire for a simple, standardized way for Modicon's own controllers to communicate with other pieces of equipment. Introduced in 1979, Modbus was originally designed to be used with their PLCs. This early version was not intended to be a universal, public standard initially; rather, it was an internal communication method developed to solve a pressing integration problem on the factory floor.

The decision to make the protocol publicly available and non-proprietary was a significant turning point. This act of openness ensured that any vendor could implement the protocol without needing to license technology or pay royalties, effectively turning a proprietary solution into an industry standard very quickly. This characteristic—being an open protocol—is arguably the single biggest factor explaining why a protocol developed over four decades ago remains relevant today, even as newer, more complex standards have emerged. In an era where proprietary lock-in was common, Modicon’s choice significantly lowered the barrier to entry for device manufacturers wanting to communicate with PLCs.

The first iteration of Modbus was built around serial communication methods, specifically utilizing the RS-232 and later RS-485 physical layers. This is where the protocol’s initial forms, Modbus RTU and Modbus ASCII, were born, which relate directly to how the data is formatted and transmitted over these serial lines.

# Serial Flavors

Modbus, in its original form, is a request/response protocol that operates on a master/slave or client/server model. The master (client) sends a request to a specific slave (server) device, which then processes the request and returns a response. Understanding the differences between the two primary serial variants is key to appreciating its application in legacy or low-bandwidth environments.

# RTU vs. ASCII

The two main serial implementations are Modbus RTU (Remote Terminal Unit) and Modbus ASCII. The fundamental difference lies in how the data is encoded for transmission.

Modbus RTU transmits data in a compact binary format. This binary encoding is efficient because it packs more information into each transmitted byte. However, because it is binary, it requires a precise timing mechanism to determine where one message ends and the next begins, which is handled by a defined time gap, or silence, in the transmission line.

Conversely, Modbus ASCII transmits data using human-readable ASCII characters. While this makes debugging over a simple terminal much easier—you can literally read the transmitted data—it is far less efficient than RTU because each byte of data requires two ASCII characters to represent it. To maintain communication synchronization, ASCII mode uses start and end characters (a colon and carriage return/line feed) rather than relying solely on silent time gaps.

A useful comparison point is overhead. If you need to transmit a single byte of data (e.g., the value 255 or 0xFF), RTU sends that single byte. ASCII must send three characters: :, F, F, followed by the line terminators. This efficiency difference often favors RTU for high-volume data transfer over serial connections.

# Error Checking

Another differentiator between the two serial modes is the method of error checking. RTU employs a Cyclic Redundancy Check (CRC), which is a very strong mathematical method for detecting transmission errors. ASCII, on the other hand, uses a much simpler Longitudinal Redundancy Check (LRC) for error detection. The superior error detection of CRC helps explain why RTU became the more dominant standard for serial industrial communication.

Who invented streaming audio protocols?

# Ethernet Integration

As industrial networks began to transition from dedicated serial wiring to standard Ethernet infrastructure, Modbus needed an adaptation. This led to the creation of Modbus TCP/IP.

Modbus TCP/IP essentially takes the original Modbus message structure (the function codes, register addresses, and data) and encapsulates it within standard TCP/IP packets. This allows Modbus commands to travel over standard Ethernet networks, bypassing the physical limitations of RS-485 wiring and leveraging the existing IT infrastructure. This variation eliminated the need for separate error-checking mechanisms like CRC or LRC because TCP/IP handles network-level error checking, and it also removed the timing constraints associated with serial communication.

It is important to note that while Modbus TCP/IP uses modern networking, the core messaging structure—the way data is requested and what types of data registers are addressed—remains fundamentally the same as the original 1979 serial design.

# Data Structure

Modbus organizes data into four primary register types, which a master device queries to read or write values. Understanding these four types is crucial for anyone interacting with a Modbus device:

1. Coils: Single digital outputs, read/write status bits.
2. Discrete Inputs: Single digital inputs, read-only status bits.
3. Input Registers: 16-bit input values, read-only.
4. Holding Registers: 16-bit values that can be read or written to by the master.

The protocol uses a function code within the request to specify which of these four types of data the master wishes to access, and further defines whether the operation is a read or a write action.

This simple, consistent addressing scheme, where devices are addressed by a Unit ID (for serial) or IP address (for TCP/IP), and data is accessed by a specific register number, provides a predictable environment for engineers.

Who invented FHIR protocols?

# Enduring Appeal

Despite its age, Modbus is often described as the "grandfather of IoT communication" and continues to see massive adoption, particularly in the Building Management Systems (BMS) sector and within legacy industrial installations.

The simplicity that allowed it to be invented quickly in 1979 is the very trait that ensures its continued success. When integrating a new sensor or a small device, implementing a full, modern protocol stack can introduce significant overhead in terms of processing power, memory, and licensing costs. Modbus, however, requires very little to implement. For small-scale automation tasks or simple data polling, the low overhead of the Modbus message structure translates directly into lower hardware costs and faster development time for device makers.

It is telling that a protocol which predates the widespread use of TCP/IP by nearly two decades has successfully transitioned across physical media, from dedicated RS-485 cabling to modern fiber optics and standard office networks. This adaptability shows the strength of the data model over the physical layer it runs on. When you look at a modern industrial gateway today, it often has a serial port running Modbus RTU on one side, gathering data from older equipment, and an Ethernet port running Modbus TCP/IP on the other, sending that data up to a cloud platform. This bridging capability is something few other protocols manage as natively.

However, this simplicity comes with recognized trade-offs. The original Modbus specification has no inherent security features. Data is transmitted in clear text, making it vulnerable to eavesdropping or malicious manipulation. While industrial users often place Modbus traffic on secure, isolated networks, its use in IP-based systems requires careful attention to network segmentation and the addition of security layers outside the protocol itself to manage risks associated with unauthorized access or command injection.

# Evolution and Management

While Modicon created the protocol, its management evolved as it became an industry standard. Schneider Electric, having acquired Modicon, continues to maintain the specifications. However, because it is an open standard, various organizations and individuals have created extensions or implemented it in non-standard ways over the years. For instance, an original device might not support reading a 32-bit register, or a vendor might use a specific function code in an unverified manner.

This decentralization of implementation has led to the necessity of various interpretation guides or profiles, often specific to a device manufacturer or an industry vertical. The concept of a "device profile document" is crucial in modern Modbus deployments: an engineer must often consult the documentation for a specific Modbus device to confirm exactly which register addresses map to which physical parameters and what the expected data format (word order, integer size) is, as the base specification leaves some room for interpretation.

The decision by Modicon to make the protocol open, combined with its inherent simplicity and the existence of robust serial and modern TCP/IP versions, cemented its position. It remains the go-to choice for simple, low-cost device integration, proving that sometimes the most enduring solutions are those that solve a basic problem elegantly, rather than those that attempt to solve every conceivable future problem at once. While newer protocols like OPC UA offer enhanced security and richer data modeling, Modbus’s ubiquity and ease of deployment ensure it is not going anywhere soon; it is the universal translator that nearly every piece of industrial hardware speaks.
